CET Modular Inverter TSI MEDIA 120 Vac 48Vdc 1.5KVA 1.2KW P/N T331330201

Name: CET Modular Inverter TSI MEDIA 120 Vac 48Vdc 15KVA 12KW PN T331330201
Brand: CE+T
Price: 99 USD

Quality CET Modular Inverter TSI MEDIA 120 Vac 48Vdc 1.5KVA 1.2KW P/N T331330201 wholesale

Brand Name : CE+T

Model Number : TSI MEDIA 120 Vac

Certification : CE

Place of Origin : CN

MOQ : 10

Price : 99 USD

Supply Ability : 500 sets / month

Delivery Time : 2-4 weeks

Packaging Details : Wooden cartons

Brand : CE+T

Product Name : Modular inverters

Part No. : T331330201

DC voltage (input range) : 48 Vdc (40 – 60)

AC voltage (input range) : 120 Vac (100 – 138)

Output power : 1.5 kVA / 1.2 kW

Efficiency: DC/AC : 90%

Efficiency: AC/AC : 94%

Weight : 4kg

Contact Now

CET Modular Inverter TSI MEDIA 120 Vac 48Vdc 1.5KVA 1.2KW P/N T331330201

CET Modular Inverter TSI MEDIA 120 Vac 48Vdc 1.5KVA 1.2KW inverter (P/N.:T331330201)

Description:

Media is a modular inverter converting 48 Vdc power source into a pure 120 Vac sine wave. By using several modules,
we can offer solutions for two-phase (2x120Vac + N) or three-phase (3x208Vac + N) infrastructures.

The extra AC input ensures a high overall efficiency (up to 94%) which results in a reduction of energy loss and heat dissipation.

Low Mean Time To Repair (MTTR) and hot swappable, this module is designed to provide you a reliable AC backup solution

and meet your needs from 1.5 kVA up to 48 kVA.

The low ripple voltage avoids any disturbances on DC loads and batteries.

Key features:

Extra AC input for increased efficiency
For loads from 1.5 kVA
Compact design
No disturbances on DC loads & batteries

Application:

CET Modular Inverter TSI MEDIA 120 Vac 48Vdc 1.5KVA 1.2KW P/N T331330201

Parameters:

In: DC voltage (input range)	48 Vdc (40 – 60)
In/Out: AC voltage (input range)	120 Vac (100 – 138)
Output power	1.5 kVA / 1.2 kW
Efficiency: DC/AC	90%
Efficiency: AC/AC	94%
Temperature	-20 to 65° C
Dimension	2U x 103 mm x 267 mm
Part number	T331330201
